Threaded End Vs Flanged End Marine Simplex Oil Filter Application Difference
Marine simplex oil filter is divided into threaded end and flanged end types based on pipeline connection mode, targeting different onboard pipe diameter and pressure working scenarios. Threaded marine simplex oil filter features small caliber, compact size, no welding needed during installation, perfect for small-bore auxiliary oil pipelines, yacht engine oil loops and ship instrument hydraulic pipelines. It is easy to disassemble for temporary replacement, ideal for low-pressure indoor cabin oil systems below 0.6MPa working pressure. Flanged end simplex oil filter owns reinforced connecting port, strong shock resistance and tight sealing performance, adapting to large-bore main branch oil pipelines, outdoor deck oil pipes with strong ship vibration. Flanged models bear up to 1.0MPa working pressure, fit for heavy medium oil filtration. Both connection versions adopt reusable filter mesh, comply with CB/T industry standard, support customized mesh precision from 40mesh to 200mesh. Ship piping designers choose threaded simplex filters for narrow installation space, and flanged simplex filters for outdoor high-vibration deck pipelines to guarantee long-term leak-free oil filtration performance at sea.
